具備高可靠性與優異防水性能，可提供穩定的訊號與電力傳輸。廣泛應用於工業自動化、感測器、通訊設備及戶外設備。
Product Overview
产品简介
標準M12工業規格設計
高防護等級性能
穩固抗震連接結構
产品介绍
规格表
相关应用
产品介绍
规格表
相关应用
Product Description
产品介绍
連接器類型: M12 Size
防水等級: IP67~IP68 Waterproof Connector
組裝類型: Panel Mount, Molded with Cable, Field Installable
溫度範圍: [Conn. Body]-40°C~100°C材質: [Conn. Body] Nylon+ GF, PPE, TPU, UL Recognized; [Pin] Copper Alloy, Gold Plated
端子型式
適用電流: 0.5A, 2A, 5A
端子數: 3~5, 8 contacts
Specifications
规格表
产品筛选
99+
汇出筛选结果
关键字搜寻
筛选条件
M12 Sensor (Field Installable (Solder)) Connector
M12 Sensor (Molded with Cable) Connector
M12 Sensor (Panel Front Mount) Connector
M12 Sensor (Panel Rear Mount) Connector
M12 Sensor (Socket with Cable) Connector
M12 Sensor I Adaptor
M12 Sensor Waterproof Cap
180° Screw Mating; PU Cable; Cable ODØ: max 7.0mm
180° Screw Mating; PVC Cable; Cable ODØ: max 7.0mm
180° Screw mating; PVC Cable; Cable ODØ: max 7.0mm
90° Screw Mating; PU Cable; Cable ODØ: max 6.0mm
90° Screw Mating; PU Cable; Cable ODØ:max 6.0mm
90° Screw Mating; PVC Cable; Cable ODØ: max 6.0mm
Accessory of M12 Connector
Hexagon Backshell, Panel Thickness: max 3.5mm; Panel Cut: Ø15.4mm x 13.7mm
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.2mm x 13.6mm
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø16.1mm x 13.6mm
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.5mm; Panel Cut: Ø15.2mm x 13.6mm
Screw Mating; Cable ODØ: max 6.0mm
Screw Mating; Seala for Cable OD Ø4.0mm~6.5mm
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.2mm x 13.6mm
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.4mm x 13.7mm
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.5mm; Panel Cut: Ø15.2mm x 13.6mm
Solder Pin; Rear Mounting; Hexagon Backshell; Panel Thickness: max 3.5mm; Panel Cut: Ø15.2mm x 13.6mm
Solder Pin; Rear Mounting; Hexagon Backshell; Panel Thickness: max 5.0mm; Panel Cut: Ø15.2mm x 13.6mm
---
3 Pins
3,4,5 Pins
4 Pins
4,5 Pins
8 Pins
---
2A, A-Code
2A, D-Code
5A, A-Code
5A, D-Code
IP65, IP67
IP67
IP68
---
Female conn
Male conn
Male to Male
确认搜寻
No Matching Results
筛选无结果
目前无符合条件的产品，请调整或重新设定筛选条件。
左右拖拉查看
产品图片
产品名称
Type-1
Type-2
PIN
Rating
Waterproof Rating
Matching
Accessories
其他功能
2MT3000-X08200
M12 Sensor (Panel Rear Mount) Connector
Solder Pin; Rear Mounting; Hexagon Backshell; Panel Thickness: max 3.5mm; Panel Cut: Ø15.2mm x 13.6mm
8 Pins
2A, A-Code
IP68
Female conn
-
2MT3000-X0X300
M12 Sensor (Panel Rear Mount) Connector
Solder Pin; Rear Mounting; Hexagon Backshell; Panel Thickness: max 3.5mm; Panel Cut: Ø15.2mm x 13.6mm
3,4,5 Pins
5A, A-Code
IP68
Female conn
-
2MT3001-X08200
M12 Sensor (Panel Rear Mount) Connector
Solder Pin; Rear Mounting; Hexagon Backshell; Panel Thickness: max 5.0mm; Panel Cut: Ø15.2mm x 13.6mm
8 Pins
2A, A-Code
IP68
Male conn
-
2MT3001-X0X300
M12 Sensor (Panel Rear Mount) Connector
Solder Pin; Rear Mounting; Hexagon Backshell; Panel Thickness: max 5.0mm; Panel Cut: Ø15.2mm x 13.6mm
3 Pins
5A, A-Code
IP68
Male conn
-
2MT3002-X08200
M12 Sensor (Panel Front Mount) Connector
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.2mm x 13.6mm
8 Pins
2A, A-Code
IP68
Female conn
-
2MT3002-X0X300
M12 Sensor (Panel Front Mount) Connector
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.2mm x 13.6mm
3,4,5 Pins
5A, A-Code
IP68
Female conn
-
2MT3003-X08200
M12 Sensor (Panel Front Mount) Connector
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.5mm; Panel Cut: Ø15.2mm x 13.6mm
8 Pins
2A, A-Code
IP68
Male conn
-
2MT3003-X0X300
M12 Sensor (Panel Front Mount) Connector
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.5mm; Panel Cut: Ø15.2mm x 13.6mm
3,4,5 Pins
5A, A-Code
IP68
Male conn
-
2MT3004-X08200
M12 Sensor (Panel Front Mount) Connector
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.2mm x 13.6mm
8 Pins
2A, A-Code
IP68
Female conn
-
2MT3004-X0X300
M12 Sensor (Panel Front Mount) Connector
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.2mm x 13.6mm
3,4,5 Pins
5A, A-Code
IP68
Female conn
-
2MT3005-X08200
M12 Sensor (Panel Front Mount) Connector
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.5mm; Panel Cut: Ø15.2mm x 13.6mm
8 Pins
2A, A-Code
IP68
Male conn
-
2MT3005-X0X300
M12 Sensor (Panel Front Mount) Connector
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.5mm; Panel Cut: Ø15.2mm x 13.6mm
3,4,5 Pins
5A, A-Code
IP68
Male conn
-
2MT3402-W0X300H
M12 Sensor (Panel Front Mount) Connector
Solder Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø15.4mm x 13.7mm
3,4,5 Pins
5A, D-Code
IP67
Female conn
-
2MT3404-W0X300H
M12 Sensor (Panel Front Mount) Connector
PCB Pin; Front Mounting; Hexagon Backshell; Panel Thickness: max 4.0mm; Panel Cut: Ø16.1mm x 13.6mm
3,4,5 Pins
5A, D-Code
IP67
Female conn
-
2MT3010-X08200
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PVC Cable; Cable ODØ: max 7.0mm
8 Pins
2A, A-Code
IP67
Female conn
-
2MT3010-X0X300
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PVC Cable; Cable ODØ: max 7.0mm
3,4,5 Pins
5A, A-Code
IP67
Female conn
-
2MT3020-X08200
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PU Cable; Cable ODØ: max 7.0mm
8 Pins
2A, A-Code
IP68
Female conn
-
2MT3020-X0X300
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PU Cable; Cable ODØ: max 7.0mm
3,4,5 Pins
5A, A-Code
IP68
Female conn
-
2MT3011-X08200
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PVC Cable; Cable ODØ: max 6.0mm
8 Pins
2A, A-Code
IP67
Female conn
-
2MT3011-X0X300
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PVC Cable; Cable ODØ: max 6.0mm
3,4,5 Pins
5A, A-Code
IP67
Female conn
-
2MT3021-X08200
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PU Cable; Cable ODØ:max 6.0mm
8 Pins
2A, A-Code
IP68
Female conn
-
2MT3021-X0X300
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PU Cable; Cable ODØ: max 6.0mm
3,4,5 Pins
5A, A-Code
IP68
Female conn
-
2MT3012-X08200
M12 Sensor (Molded with Cable) Connector
180° Screw mating; PVC Cable; Cable ODØ: max 7.0mm
8 Pins
2A, A-Code
IP67
Male conn
-
2MT3012-X0X300
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PVC Cable; Cable ODØ: max 7.0mm
3,4,5 Pins
5A, A-Code
IP67
Male conn
-
2MT3022-X08200
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PU Cable; Cable ODØ: max 7.0mm
8 Pins
2A, A-Code
IP68
Male conn
-
2MT3022-X0X300
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PU Cable; Cable ODØ: max 7.0mm
3,4,5 Pins
5A, A-Code
IP68
Male conn
-
2MT3013-X08200
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PVC Cable; Cable ODØ: max 6.0mm
8 Pins
5A, A-Code
IP67
Male conn
-
2MT3013-X0X300
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PVC Cable; Cable ODØ: max 6.0mm
3,4,5 Pins
2A, A-Code
IP67
Male conn
-
2MT3023-X08200
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PU Cable; Cable ODØ: max 6.0mm
8 Pins
2A, D-Code
IP68
Male conn
-
2MT3023-X0X300
M12 Sensor (Molded with Cable) Connector
90° Screw Mating; PU Cable; Cable ODØ: max 6.0mm
3,4,5 Pins
5A, D-Code
IP68
Male conn
-
2MT3050-X08201H
M12 Sensor (Molded with Cable) Connector
180° Screw Mating; PVC Cable; Cable ODØ: max 7.0mm
8 Pins
2A, D-Code
IP65, IP67
Female conn
-
2MT3D04-X04302H
M12 Sensor (Socket with Cable) Connector
Hexagon Backshell, Panel Thickness: max 3.5mm; Panel Cut: Ø15.4mm x 13.7mm
4 Pins
5A, D-Code
IP67
Female conn
-
2MT3032-X08200
M12 Sensor (Field Installable (Solder)) Connector
Screw Mating; Cable ODØ: max 6.0mm
8 Pins
2A, A-Code
IP67
Female conn
-
2MT3032-X0X300
M12 Sensor (Field Installable (Solder)) Connector
Screw Mating; Cable ODØ: max 6.0mm
3,4,5 Pins
5A, A-Code
IP67
Female conn
-
2MT3033-X08200
M12 Sensor (Field Installable (Solder)) Connector
Screw Mating; Seala for Cable OD Ø4.0mm~6.5mm
8 Pins
2A, A-Code
IP67
Male conn
-
2MT3033-X0X300
M12 Sensor (Field Installable (Solder)) Connector
Screw Mating; Seala for Cable OD Ø4.0mm~6.5mm
3,4,5 Pins
5A, A-Code
IP67
Male conn
-
2MT3D33-X0X300H
M12 Sensor (Field Installable (Solder)) Connector
Screw Mating; Seala for Cable OD Ø4.0mm~6.5mm
4,5 Pins
5A, D-Code
IP67
Male conn
-
2MT302A-X03300
M12 Sensor I Adaptor
Accessory of M12 Connector
3 Pins
5A, A-Code
IP67
Male to Male
-
2MT3010-X0000W
M12 Sensor Waterproof Cap
Accessory of M12 Connector
---
---
IP68
---
-
2MT3012-X0000W
M12 Sensor Waterproof Cap
Accessory of M12 Connector
---
---
IP68
---
-
